centos7+hadoop2.8.0 full cluster

hadoop完全分布式安装

环境

1. 主机：3台centos7主机，用户名和密码都设置为root/root，hd/hd
2. hadoop版本：hadoop2.8.0
3. jdk版本：java1.8.0

配置节点

1. 设置主机ip

   主机 IP 对应角色
   master 192.168.140.135 namendoe
   slave1 192.168.140.136 datanode
   slave2 192.168.140.137 datanode

2. 永久修改hostname 分别设为

   hostnamectl set-hostname master
   hostnamectl set-hostname slave1
   hostnamectl set-hostname slave2

3. 设置 /etc/hosts文件 ，添加如下

   192.168.140.135 master
   192.168.140.136 slave1
   192.168.140.137 slave2

查看java版本,确保java已经安装

[hd@master bigdata]$ java -version
java version "1.8.0_131"
Java(TM) SE Runtime Environment (build 1.8.0_131-b11)
Java HotSpot(TM) 64-Bit Server VM (build 25.131-b11, mixed mode)
[hd@master bigdata]$

关闭防火墙，关闭firewall

1. 查看防火墙状态

   [root@master ~]# firewall-cmd –state
   running

2. 停止服务

   [root@master ~]# systemctl stop firewalld.service
   [root@master ~]# firewall-cmd –state
   not running

3. 禁用防火墙

   [root@master ~]# systemctl disable firewalld.service
   Removed symlink /etc/systemd/system/dbus-org.fedoraproject.FirewallD1.service.
   Removed symlink /etc/systemd/system/basic.target.wants/firewalld.service.
   [root@master ~]# firewall-cmd –state
   not running

hd作为大数据环境用户，给hd用户增加sudo权限

[root@master ~]# ll /etc/sudoers
-r-xr-----. 1 root root 3907 Nov  4  2016 /etc/sudoers
[root@master ~]# chmod u+w /etc/sudoers
[root@master ~]# vi /etc/sudoers
    ## Allow root to run any commands anywhere
    root    ALL=(ALL)       ALL
    hd      ALL=(ALL)NOPASSWD:ALL
[root@master ~]# chmod u-w /etc/sudoers

切换到hd用户下,配置SSH免密码登录

ssh-keygen  -t   rsa   -P  ''
cp id_rsa.pub authorized_keys

配置jdk

[hd@master bigdata]$ sudo vi /etc/profile

export JAVA_HOME=/usr/local/bigdata/jdk1.8
export CLASSPATH=$CLASSPATH:$JAVA_HOME/lib/
export PATH=$PATH:$JAVA_HOME/bin

配置Hadoop

1. 编辑hadoop-env.sh

    #The java implementation to use.
    export JAVA_HOME=/usr/local/bigdata/jdk1.8


2. 编辑core-site.xml

    <configuration>
        <property>
            <name>hadoop.tmp.dir</name>
            <value>/hd/hadoop/tmp</value>
            <description>Abase for other temporary directories.</description>
        </property>

        <property>
            <name>fs.default.name</name>
            <value>hdfs://master:9000</value>
        </property>
    </configuration>


3. 编辑hdfs-site.xml

    <configuration>
        <property>
           <name>dfs.name.dir</name>
           <value>/hd/hadoop/dfs/name</value>
           <description>Path on the local filesystem where theNameNode stores the namespace and transactions logs persistently.</description>
        </property>

        <property>
           <name>dfs.data.dir</name>
           <value>/hd/hadoop/dfs/data</value>
           <description>Comma separated list of paths on the localfilesystem of a DataNode where it should store its blocks.</description>
        </property>

        <property>
           <name>dfs.replication</name>
           <value>2</value>
        </property>

        <property>
              <name>dfs.permissions</name>
              <value>false</value>
              <description>need not permissions</description>
        </property>
    </configuration>


4. 编辑mapred-site.xml

    <configuration>
        <property>
            <name>mapred.job.tracker</name>
            <value>master:49001</value>
        </property>

        <property>
              <name>mapred.local.dir</name>
               <value>/hd/hadoop/var</value>
        </property>

        <property>
               <name>mapreduce.framework.name</name>
               <value>yarn</value>
        </property>
    </configuration>


5. 修改hadoop/etc/hadoop/slaves文件，修改如下

    slave1
    slave2


6. 编辑yarn-site.xml

    <configuration>
        <property>
            <name>yarn.resourcemanager.hostname</name>
            <value>master</value>
        </property>

        <property>
            <description>The address of the applications manager interface in the RM.</description>
            <name>yarn.resourcemanager.address</name>
            <value>${yarn.resourcemanager.hostname}:8032</value>
        </property>

        <property>
            <description>The address of the scheduler interface.</description>
            <name>yarn.resourcemanager.scheduler.address</name>
            <value>${yarn.resourcemanager.hostname}:8030</value>
        </property>

        <property>
            <description>The http address of the RM web application.</description>
            <name>yarn.resourcemanager.webapp.address</name>
            <value>${yarn.resourcemanager.hostname}:8088</value>
        </property>

        <property>
            <description>The https adddress of the RM web application.</description>
            <name>yarn.resourcemanager.webapp.https.address</name>
            <value>${yarn.resourcemanager.hostname}:8090</value>
        </property>

        <property>
            <name>yarn.resourcemanager.resource-tracker.address</name>
            <value>${yarn.resourcemanager.hostname}:8031</value>
        </property>

        <property>
            <description>The address of the RM admin interface.</description>
            <name>yarn.resourcemanager.admin.address</name>
            <value>${yarn.resourcemanager.hostname}:8033</value>
        </property>

        <property>
            <name>yarn.nodemanager.aux-services</name>
            <value>mapreduce_shuffle</value>
        </property>

        <property>
            <name>yarn.scheduler.maximum-allocation-mb</name>
            <value>2048</value>
            <discription>每个节点可用内存,单位MB,默认8182MB</discription>
        </property>

        <property>
            <name>yarn.nodemanager.vmem-pmem-ratio</name>
            <value>2.1</value>
        </property>

        <property>
            <name>yarn.nodemanager.resource.memory-mb</name>
            <value>2048</value>

        </property>
           <property>
                <name>yarn.nodemanager.vmem-check-enabled</name>
                <value>false</value>
        </property>
    </configuration>
